Portable Wheel Wash Machine DCX-40T
- Non-standard wheel washer
- No civil foundation is needed
Contact us for a price
Speak To A Car Washing Machine Specialist
Specifications
Portable Wheel Wash Machine DCX-40T Details
The portable wheel washing machine can be used on any site, and its biggest advantage is that it does not need to be a civil foundation work and can be easily replaced. However, since this is a customized device, the customer needs to provide information about the maximum truck width.
| Item | Parameter |
|---|---|
| Model | DCX-40T |
| Equipment Size (mm) | 2200(W)x4950(L)x1820(H) |
| Ramp length (mm) | 6000~9000, adjustable |
| Max truck width (mm) | 2800 |
| Weight | 3200kg |
| Wash way | Drive through type |
| Wash for | <80 tons engineering truck, transport vehicle |
| Start way | Mechanical sensing start |
| Wash pressure | 3kg/cm² |
| Wash time | 60-80sec/ vehicle |
| Water used | 10L/vehicle |
| Machine total power | 23KW |
| Material | Galvanizing framework |
| Sewage | Remove mud manually |
| Power supply | 380V, 50Hz, 3P; Accept custom |
| Side nozzle | Φ4.2, 42pcs |
Main Features
● Portable wheel wash system
● Equipped water circulating system
● Equipped 4CBM water tank beside the machine
● Equipped 2pcs water pumps, one is washing pump 15kw, flow 1200L/min, the other one is circulating pump 7.5kw, flow 1200L/ min
Frame drawing
Washing video
Factory View
Trusted Clients
More and more clients choose to trust and cooperate with TOPWELL
Services
Customization Steps
Discuss Your Needs
Tailored Solution
Precision Manufacturing
Installation & Training
Contact us for a price
Speak To A Car Washing Machine Specialist
FAQ Guide
Portable Wheel Wash Machine DCX-40T
How to solve the installation problem?
We will provide installation drawings and online guidance.
How to solve the after-sales problem after the equipment is installed?
At present, WhatsApp and other foreign social media software cannot be opened in China without a VPN. Therefore, after cooperation, we suggest the customers download the WeChat App. Topwell will set up a separate group for each customer, which includes the salesperson and the technician in the factory. If you have any after-sales problems, you just need to describe the problem clearly and send relevant photos and videos to the group. Our technicians will guide you and provide a solution immediately.
How long is the lead time?
Standard 380V, 50HZ takes 30 working days; The non-standard voltage needs to add 10 working days on the basis of the above.
What about the payment term?
T/T in advance or L/C at sight can be negotiated
